General Function for Non-Linear Optimization/Fitting of EPR Parameters/Data

General-purpose optimization of the objective fn function (also called "fitness") which is to be minimized in order to fit theoretical models (EPR simulations) onto the experimental data. Several methods/algorithms are implemented (see also Details): from the nloptr package: slsqp, neldermead, crs2lm, sbplx, cobyla, lbfgs; from the minpack.lm package: nls.lm and finally from the pso package: psoptim.

Usage

optim_for_EPR_fitness(
  method = "neldermead",
  x.0,
  fn,
  lower,
  upper,
  data,
  Nmax.evals = 512,
  tol.step = 5e-07,
  pswarm.size = NULL,
  pswarm.diameter = NULL,
  pswarm.type = NULL,
  ...
)

Arguments

method: Character string, pointing to applied optimization method/algorithm. One may choose one from those listed in Details, default: method = "neldermead", setting up the "Nelder-Mead" simplex method.
x.0: Numeric vector with the initial values to be optimized in order to fit onto the experimental data.
fn: Objective function that is to be minimized. Usually the sum of residual squares (see Details and Examples).
lower, upper: lower and upper bound constraints.
data: Data frame object, containing columns/variables (e.g. intensity of an EPR spectrum), required to undergo a fitting/optimization process.
Nmax.evals: Numeric value, maximum number of function evaluations and/or iterations. The only one method, limited by this argument, is nls.lm, where Nmax.evals = 1024. Higher Nmax.evals may extremely extend the optimization time, therefore the default value reads Nmax.evals = 512. However, the "pswarm" method requires at least the default or even higher values.
tol.step: Numeric, the smallest optimization step (relative change) between 2 iterations to stop the optimization procedure. For the method = "pswarm" (particle swarm optimization procedure) it actually corresponds to tolerance for restarting. Once the maximum distance between the "best" particle and all the others is less than tol.step * pswarm.diameter) the algorithm restarts. See also psoptim. Default: tol.step = 5e-7.
pswarm.size: Numeric value, which equals to particle swarm size (i.e. number of particles), if method = "pswarm". The default value (pswarm.size = NULL) actually corresponds to floor(10+2*sqrt(length(x.0))) (for SPSO2007, see the pswarm.type argument), e.g. to optimize 8 parameters, number of particles = 15. For the SPSO2011 the default number of particles equals to 40.
pswarm.diameter: Numeric value, corresponding to diameter of the particle swarm search space (in case method = "pswarm"). The default value (pswarm.diameter = NULL) refers to the Euclidean distance, defined as: $$\sqrt{\sum_k\,(\text{upper}[k] - \text{lower}[k])^2}$$
pswarm.type: Character string, setting the type/version of particle swarm algorithm if method = "pswarm". There are two types available: pswarm.type = "SPSO2007" and pswarm.type = "SPSO2011". The latter introduced an adaptive random topology, which allows the swarm to dynamically adjust its communication structure. This helps in maintaining diversity in the swarm and improves the algorithm's ability to escape local optima. This type generally offers better performance on larger multidimensional spaces than the pswarm.type = "SPSO2007", which uses a more static topology. Details may be found in the References. Default: pswarm.type = NULL (actually corresponding to "SPSO2007", that performs slightly better on smaller scales such as simulations of EPR spectra).
...: additional arguments passed to the function.

Value

For all listed algorithms the function returns list with the elements like (please, refer to e.g. Value in eval_sim_EPR_isoFit)

The best parameters found (par vector, depending on the initial x.0 set of parameters).
The value of fn (minimum value) corresponding to the best par.
Number of evaluations and/or iterations (in case of the method = "pswarm", see also Value in the psoptim) before the termination.
(Un)successful termination information (convergence or rsstrace), usually corresponding either to integer value showing the (un)successful termination like 2: Maximum number of iterations reached (or integer code > 0 indicating successful completion) or in the case of nls.lm, it returns a vector with the values equal to sum of the residual squares at each iteration.
A descriptive message/character string giving additional information about the optimization procedure/termination. By default, this is however "turned off", for the sake of simplicity, because most of the information can be found in the previous convergence list element.

Details

All algorithms are based on the least-square minimization however, the fn definition in case of nls.lm must be provided as a difference/residual vector (see also eval_kinR_EPR_modelFit) and not as sum of difference/residual squares. The applied optimization/fitting methods are summarized in the following table (please, consult the details in References or in the individual function documentation - links in the Description) =>

Method/Algorithm	Package	Short Description
`slsqp`	`{nloptr}`	Sequential quadratic programming method for non-linearly constrained, gradient-based optimization.
`cobyla`	`{nloptr}`	Constrained optimization by linear approximations, algorithm for derivative-free optimization with nonlinear inequality and equality constraints.
`lbfgs`	`{nloptr}`	Low-storage version of the Broyden-Fletcher-Goldfarb-Shanno (BFGS) method. This is a quasi-Newton method well suited for the optimization problems with a large number of variables.
`neldermead`	`{nloptr}`	Nelder-Mead ("N-M") simplex algorithm.
`crs2lm`	`{nloptr}`	Controlled Random Search (CRS) algorithm (and in particular, the CRS2 variant) with the `local mutation' modification.
`sbplx`	`{nloptr}`	Subplex algorithm, which is a variant of the "N-M" method on a sequence of sub-spaces.
`nls.lm` (`levenmarq`)	`{minpack.lm}`	Modified Levenberg-Marquardt algorithm. It is a combination of gradient descent and Gauss-Newton method.
`psoptim` (`pswarm`)	`{pso}`	Particle swarm optimization, which is a population-based stochastic optimization algorithm motivated by the intelligent collective behavior of some animals such as flocks of birds or schools of fish.

Not all {nloptr}-methods are implemented into the optim_for_EPR_fitness. Those summarized above were tested by the EPR simulation fit (see eval_sim_EPR_isoFit) on the experimental spectra of TEMPOL and Wuster's blue radicals. They provide the best results (without extensive "playing" with nl.opts, i.e. with options to control the optimization procedure) and proceed relatively fast.

References

Johnson SG (2023). “The NLopt nonlinear-optimization package.” https://github.com/stevengj/nlopt.

Stamm A (2023). “nloptr.” https://github.com/astamm/nloptr/.

Mullen KM, Elzhov TV, Spiess A, Bolker B (2023). “minpack.lm.” https://github.com/cran/minpack.lm.

Gavin HP (2019). “The Levenberg-Marquardt algorithm for nonlinear least squares curve-fitting problems.” Department of civil and environmental engineering, Duke University, https://people.duke.edu/~hpgavin/lm.pdf.

Adyatama A (2019). “Particle Swarm Optimization.” https://rpubs.com/argaadya/intro-pso.

Tam A (2021). “A Gentle Introduction to Particle Swarm Optimization.” https://machinelearningmastery.com/a-gentle-introduction-to-particle-swarm-optimization/.

Ugolotti R, Cagnoni S (2016). "A Fair Comparison Between Standard PSO Versions." In: Rossi F, Mavelli F, Stano P, Caivano D (eds), Advances in Artificial Life, Evolutionary Computation and Systems Chemistry, WIVACE 2015, Communications in Computer and Information Science, Springer, https://doi.org/10.1007/978-3-319-32695-5_1.

Zambrano-Bigiarini M, Clerc M, Rojas-Mujica R (2013). "Standard Particle Swarm Optimisation 2011 at CEC-2013: A baseline for future PSO improvements." 2013 IEEE Congress on Evolutionary Computation, https://ieeexplore.ieee.org/document/6557848.

Examples

if (FALSE) { # \dontrun{
## following code snippets were taken from
## the `quantify_EPR_Sim_series` function
#
## if an EPR spectrum consists of several
## components or several radical spectra partly overlay,
## following simple function, taking the linear
## combination of EPR simulated intensities (max. 6),
## can be applied in order to fit the sum of the individual
## simulations onto the experimental EPR spectrum
## envelope, the input parameters therefore correspond
## to zero-point/intercept(par[1]) and coefficients
## of the linear combinations(par[2]...par[7]),
## equal to individual intensity multiplications:
fit_params_specs_par <- function(data,
                                 col.name.pattern,
                                 par){
  #
  # data contains variables/columns of simulated
  # intensities with the headers characterized
  # by the `col.name.patter`
  #
  data <- data[,grep(col.name.pattern,
                     colnames(data),
                     value = TRUE)]
  #
  ## create a sum for all columns/simulated spectra
  if (ncol(data) == 1){
    summa <- par[1] + (par[2] * data[[1]])
  }
  if (ncol(data) == 2){
      summa <- par[1] + (par[2] * data[[1]]) +
      (par[3] * data[[2]])
  }
  if (ncol(data) == 3){
    summa <- par[1] + (par[2] * data[[1]]) +
      (par[3] * data[[2]]) +
      (par[4] * data[[3]])
  }
  if (ncol(data) == 4){
    summa <- par[1] + (par[2] * data[[1]]) +
      (par[3] * data[[2]]) +
      (par[4] * data[[3]]) +
      (par[5] * data[[4]])
  }
  if (ncol(data) == 5){
    summa <- par[1] + (par[2] * data[[1]]) +
      (par[3] * data[[2]]) +
      (par[4] * data[[3]]) +
      (par[5] * data[[4]]) +
      (par[6] * data[[5]])
  }
  if (ncol(data) == 6){
    summa <- par[1] + (par[2] * data[[1]]) +
      (par[3] * data[[2]]) +
      (par[4] * data[[3]]) +
      (par[5] * data[[4]]) +
      (par[6] * data[[5]]) +
      (par[7] * data[[6]])
  }
  #
 return(summa)
 }
 #
 ## following function is applied to vary only
 ## `method`, `function` and `data`
optim_fn <- function(fun,method,data){
  optim.list <-
    optim_for_EPR_fitness(x.0 = optim.params.init,
                          method = method,
                          fn = fun,
                          lower = optim.params.lower,
                          upper = optim.params.upper,
                          Nmax.evals = Nmax.evals,
                          tol.step = tol.step,
                          pswarm.size = pswarm.size,
                          pswarm.diameter = pswarm.diameter,
                          data = data,
                          col.name.pattern =
                          "Sim.*_[[:upper:]]$"
    )
  #
  return(optim.list)
 }
#
## finally, the following function is to be minimized:
min_residuals_ps <- function(data,col.name.pattern,par){
  with(data,sum((data[[Intensity.expr]] -
    fit_params_specs_par(data,col.name.pattern,par))^2)
    )
  }
#
## therefore, the final `optimization` list may look like
optimization.list <-
  lapply(seq(data.list),
         function(o) {
         optim_fn(method = optim.method,
         data = data.list[[o]],
         fun = min_residuals_ps)
       }
    )
## where `data.list` represents the list of data frames
## including all individual simulated spectra
## (one data frame for each spectrum + original
## experimental spectrum intensity column)
#
} # }
